Zhejiang Vermillion Import and Export Co., Ltd. builds hydraulic log splitters inside a wider programme of hydraulic machinery and maintenance tools that also covers auto repair equipment, garage equipment and motorcycle maintenance tools. Our Log Splitter Manufacturers line is hydraulic throughout, with three production models spanning 8-tonne vertical and 10-tonne horizontal splitting, fixed and wheeled frames, and log capacities up to 470 mm in length. We supply distributors, farm and outdoor power equipment wholesalers, brand sellers and engineering clients who process firewood, clear land or handle timber on a recurring basis.
What We Manufacture in the Log Splitter Range
Every model in the range uses a hydraulic ram to drive the splitting wedge, so force is applied progressively through the log rather than as a single impact. The three models differ in splitting orientation, frame type and rated force, which is what determines where each one fits.
A fixed-frame horizontal splitter with 10-tonne rated force and a 180 mm ram stroke. Maximum log length is 470 mm, covering standard firewood lengths. Net weight is approximately 40 kg, packaged at 112 × 26 × 29 cm with 352 units per 20-foot container. Built for farm, rural and outdoor log processing where the machine stays in one working position.
The same 10-tonne force and 180 mm ram stroke as the OY1210, mounted on a wheeled transport frame so the unit can be moved between splitting locations without lifting equipment. Net weight is approximately 50 kg, with the same 112 × 26 × 29 cm package and 352 units per 20-foot container. Two splitter knife shapes are available on this model, which is the most widely ordered configuration in the range.
A vertical splitter rated at 8 tonnes, designed for rounds that are easier to stand upright than to lift onto a horizontal bed. Net weight is approximately 33.5 kg with a compact 73 × 33 × 29 cm package, which keeps handling and on-site repositioning straightforward.
Model Range and Technical Data
| Model | Splitting configuration | Rated force | Max. log capacity | Net weight | Package size (cm) | Qty / 20' CY |
|---|---|---|---|---|---|---|
| OY1210 | Horizontal, fixed frame | 10 t | 470 mm length | 40 kg | 112 × 26 × 29 | 352 pcs |
| OY1217 | Horizontal, wheeled frame | 10 t | 470 mm length | 50 kg | 112 × 26 × 29 | 352 pcs |
| OY1218 | Vertical | 8 t | 21 in length / 13 in diameter | 33.5 kg | 73 × 33 × 29 | — |
Application Fit: Horizontal, Wheeled and Vertical Splitting
- Fixed horizontal (OY1210) — a stationary splitting station for farms, rural properties and outdoor recreation businesses that process a large seasonal firewood volume in one place.
- Wheeled horizontal (OY1217) — where timber is harvested or stored at different points across a property and the splitter has to follow the work. The wheeled frame removes the need for a second lifting tool to reposition the machine.
- Vertical (OY1218) — short, thick hardwood rounds that are awkward to balance on a horizontal bed. Standing the log upright lets the ram travel downward through the wood and keeps the operator clear of a heavy round that would otherwise need to be lifted and held.
Workshops that combine firewood processing with vehicle servicing pair these machines with our hydraulic shop press range, hydraulic jacks and engine stands from the same production programme.
Log and Material Considerations
Splitting performance is decided by the log, not only by the tonnage figure. Species density, knot content, moisture content and grain direction all change the force a round demands before it separates.
- Diameter and length — the 470 mm log length on the OY1210 and OY1217 matches standard firewood cutting; the OY1218 handles larger-diameter rounds in a vertical orientation.
- Hardwood and knots — dense, knotted hardwood is where the 10-tonne models hold their advantage, because the hydraulic ram maintains force through the full stroke rather than peaking at impact.
- Green versus seasoned timber — green wood splits with more stringing and needs steady force; seasoned rounds tend to separate more cleanly and are easier to position.
- Wedge geometry — the two splitter knife shapes offered on the OY1217 let the same machine be matched to different wood types and splitting behaviour.
Hydraulic Drive, Force and Splitting Behaviour
The hydraulic circuit delivers consistent splitting force throughout the ram stroke, which is what makes these machines effective on dense, knotted hardwood that resists a manual wedge or a single-strike tool. The 180 mm ram stroke on the 10-tonne models gives enough travel to push a standard firewood round fully past the wedge, and the 8-tonne vertical unit applies the same principle downward through the log.
Because the drive is hydraulic and self-contained, the machines need no compressed air line, no electrical supply and no fixed installation. That keeps them usable on a farm track, in a yard or at a timber stack where no workshop services are available.
Configuration, Branding and OEM/ODM Support
We build log splitters as standard models and as customer-specific configurations. The R&D and structural design team works from the working point the machine has to serve, then adjusts the build accordingly.
- Logo and packaging — laser marking of the customer brand on the machine, plus colour box, carton and user manual in English, Japanese, Spanish, French and other languages.
- Structure and parameter optimisation — adjustment of pressure, dimensions, appearance and operating structure to suit the standards and working habits of Europe, America, Southeast Asia and other regions.
- Exclusive model development — prototype design, sample production, mass production and testing for customer-specific or patented designs.
Quality Control and Acceptance
Our Jiaxing factory operates under an ISO 9001 quality management system, and core hydraulic products carry CE certification for European market sales. Production runs through full-chain workshops, automated assembly lines and a testing laboratory, with 100% full inspection applied through production to keep defective units out of the shipment.
For project orders we confirm the model, rated force, log capacity, packaging configuration and container loading plan before production, so the delivered units match the agreed specification and the shipping plan is fixed in advance.
Installation, Operation and Maintenance
- Site preparation — a level, firm surface is enough. The 40 kg OY1210 and 50 kg OY1217 units are moved with vehicle assistance; the wheeled frame on the OY1217 allows hand movement across level ground.
- Safe operation — the log is secured on the bed or splitting table and the machine is checked as being in good working condition before each session.
- Serviceability — long-term after-sales technical guidance and operation video tutorials are provided, together with lifelong low-cost spare parts supply to keep maintenance costs predictable for distributors.
Information We Use to Configure Your Solution
- Working point — log species, typical diameter and length, green or seasoned, and how much of the volume is knotted hardwood.
- Throughput target — rounds per season or per working day, and whether splitting happens at one fixed position or across several sites.
- Configuration choice — horizontal fixed, horizontal wheeled or vertical, and the splitter knife shape required.
- Market requirements — destination country, applicable standards and any certification the shipment must carry.
- Branding and packaging — logo placement, colour box and carton artwork, manual language and retail or bulk packaging.
- Order scope — trial quantity versus full-container volume, model mix and target delivery schedule.
Frequently Asked Questions
Which log splitter models does Zhejiang Vermillion manufacture?
Three hydraulic models: the OY1210 horizontal 10-tonne splitter, the OY1217 wheeled 10-tonne splitter and the OY1218 vertical 8-tonne splitter. All three use hydraulic ram drive and are supplied with the packaging and branding configuration agreed for the order.
Which model suits large-diameter hardwood rounds?
The OY1218 vertical splitter is the right fit for thick, heavy rounds, because the log stands upright on the splitting table and the ram drives downward. It removes the need to lift and balance a large round on a horizontal bed, which is the main handling difficulty with mature hardwood.
Can log splitters be produced with our own brand and packaging?
Yes. We provide OEM and ODM work covering laser-marked logos, custom colour boxes and cartons, multi-language manuals, and structural or parameter adjustments to match regional standards and operating habits. Exclusive new model development from prototype through to mass production and testing is also available.
What certifications apply to your log splitters?
The factory operates under ISO 9001 quality system certification, and core hydraulic products hold CE certification for European market sales. Certification documents relevant to the ordered models are provided with the shipment documentation.
How are trial orders and minimum order quantities handled?
Minimum order quantity is flexible on standard models. We accept small trial orders for market testing and scale to bulk, full-container cooperation as the market develops, with more favourable unit pricing at container volumes.
What information do you need to prepare a log splitter proposal?
Log species, diameter and length, green or seasoned condition, expected seasonal volume, whether splitting is fixed or mobile, destination market and standards, branding and manual language, and the intended order scope. With those details we confirm the model, configuration and container loading plan.
