OY1002 Air-Driven 1300mL Hydraulic Pump

The OY1002 Air-Driven 1300mL Hydraulic Pump is a pneumatically powered hydraulic unit that converts compressed air input into high-pressure hydraulic output, delivering up to 10,000 PSI from a 1,300 mL oil reservoir. Requiring an air supply of 100 to 120 PSI, it is suited to workshops already equipped with a compressed air system seeking a fast and responsive hydraulic power source for tools, presses, and cylinders.

The air-driven actuation enables faster hydraulic pressure build-up compared to manual hand pumps, and the no-load output flow rate of 24.4 L/min drops to approximately 7.3 L/min under load — providing a practical combination of speed and sustained pressure delivery. The 1/4"-18NPT output port is compatible with standard hydraulic fittings. With a gross weight of 14 kg and compact housing dimensions of approximately 60.5 × 26.5 × 23 cm, it is easy to position at the workstation.

This pump is a productive choice for high-frequency pressing, clamping, and force-application operations in automotive repair workshops, fabrication shops and industrial maintenance environments. The air-powered drive reduces operator fatigue compared to manual pumping, supporting faster cycle times and improved consistency in repetitive hydraulic operations. It pairs effectively with cylinders, press rams, and rescue or industrial spreading tools.
